TFT LCD module Archives

TFT LCD module (Thin Film Transistor Liquid Crystal Display Module) is a liquid crystal display module based on thin film transistor technology, which is widely used in modern electronic devices. TFT technology configures an independent thin film transistor behind each pixel to control the arrangement of liquid crystal molecules, thereby achieving high resolution, high brightness, and stable image display effects. TFT LCD module has the characteristics of high resolution, high brightness and contrast, high stability, moderate viewing angle, and fast response speed, and is widely used in many fields: automotive electronics, security equipment, industrial control equipment, police, medical equipment, power equipment, handheld terminals, smart devices, smart homes, instruments and meters, and many other industries.

Showing 1–10 of 18 results

0.9 Inch 128*128 SPI Round TFT LCD Display Module Small Circular Display Screen touch panel

Resolution： 128*128 Interface Type： SPI Display Area： 23.04*23.04(mm) LCM Dimensions： 25.24*27.14*1.94(mm) Product Dimensions： 33*33*2.79(mm)，Customizable appearance Dot Pitch： 180um*180um Color： 16.7M Contrast Ratio： 800 Response Time： 35MS Brightness： 800cd/m² Product Type： TFT Display Type： Normal Black View Angle： U/D/L/R: 85/85/85/85 (TYP) Operating Temperature: -20℃~+70℃ Storage Temperature：-30℃~+80℃ Customization： Yes

1.6 inch 400*400 Resolution MIPI QSPI Interface round touch lcd screen panel tft display module

Resolution： 400*400 Interface Type： MIPI 、QSPI Display Area： 39.84*39.84(mm) LCM Dimensions： 42.14*44.34*1.9(mm) Product size: 53*53*3.53 (mm) Dot Pitch: 33.2um*99.6um Color: 16.7M Contrast Ratio: 900 Response time: 35ms Brightness: 300cd/m² Product type: TFT Display Type: Normal Black View Angle: Full view Operating temperature: -20℃~+70℃ Storage temperature: -30℃~+80℃ Customization: Yes

10.1 Inch TFT LCD Display Module Touch Screen

Parameter of 10.1 inch tft lcd display module touch screen 1200*1920 Resolution MIPI interface Resolution： 1200*1920 Support interface： MIPI Display area： 135.36*216.58 (mm) LCM Dinensions：141.53*227.35*1.96（mm） Brightness： 400cd/m² Dot Pitch： 37.6Um*112.8Um color： 16.7M Product type： TFT Display Type： Normal Black Vier Angle： U/D/L/R:80/80/80/80 Touch type： CTP Operating tenperature： -10℃~+60℃ Storage tenperature： -20℃~+70℃ Custonisation： Yes, Touch shape can be customized

2.0 inch Full View transflective TFT LCD display screen with 240*320 MCU RGB SPI interface LCD module

Resolution： 240*320 Interface Type： MCU 、RGB 、 SPI Display area： 30.6*40.8(mm) LCM Dimensions： 36.72*52.74*2.65(mm) Dot Pitch： 0.1275mm * 0.1275mm Color： 262K Contrast Ratio： 110 Response time： 30ms Brightness： 200cd/m² Product type ：TFT Display Type： Transflective ，Semi-reflective，Normally White View Angle： Full View Operating temperature： -20℃~+70℃ Storage temperature： -30℃~+80℃ Customization： Yes

2.0 Inch TFT LCD Display Module Manufacturers

Parameter of 2.0-inch tft lcd module display Resolution： 320*240 Product ratio： 4:3 Support interface： MCU LCM Dimensions： 43.95*38.8*2.12(mm) Display area： 40.8*30.6（mm） Brightness ： 800cd/m² Product type： TFT(LTPS) Display Type： Normal Black View Angle： U/D/L/R: 80/80/80/80 Touch type： Plug-in TP Operating temperature： -20℃~+70℃ Storage temperature： -30℃~+80℃ Customisation： Yes

2.4 inch 480*600 Resolution MIPI RGB MCU interface tft lcd display touch screen LCD module

Resolution： 480*640 Support Interface： MIPI、RGB、MCU Display Area： 36.72*48.94(mm) LCM Dimensions： 42.72*60.26*2.2(mm) Dot Pitch： 76.5 Um*76.5 Um Color： 16.7M Contrast Ratio： 800:1000 Response Time： 35ms Brightness： 500cd/m² Product Type： TFT Display Type： Normal Black View Angle： ALL Operating Temperature： -20℃~+70℃ Storage Temperature： -30℃~+80℃ Customization： Yes

2.83 Inch TFT LCD Display Module Touch Screen

Parameter of 2.83 inch TFT LCD Display Module Touch Screen Resolution： 480*640 Product ratio： 4:3 Support interface： MIPI LCM Dimensions： 46.5*65.05*1.67(mm) Display area： 43.2 * 57.6 (mm) Brightness： 300cd/m²（MIN） Product type： TFT(a-si) Display Type： Normal Black View Angle： U/D/L/R: 80/80/80/80 Touch type： CTP Operating temperature： -20℃~+70℃ Storage temperature： -30℃~+80℃ Customisation： Yes

3.1 inch 480*800 Resolution MIPI RGB interface tft ONCELL touch lcd display screen module

The 3.1-inch ONCELL LCD display supports customization and is suitable for industrial control, medical treatment, smart home, and handheld terminals. It has high resolution, high brightness, and wide temperature working characteristics. Resolution: 480*800 Support interface: MIPI、RGB LCM Dimensions: 43.48*74.72*1.66(mm) Brightness: 550cd/m²（MIN） Product type: TFT(a-si) Display Type: Normal Black View Angle: U/D/L/R: 80/80/80/80 Touch type: ONCELL Display area: 40.32*67.2 (mm) Operating temperature: -20℃~+70℃ Storage temperature: -30℃~+80℃ Customization: Yes

3.95″ 720*720 RGB MIPI Interface brightness 2000cd/m² TFT LCD display touch screen module

Resolution： 720*720 Interface Type： RGB、MIPI Display area： 71.93*71.93(mm) LCM Dimensions： 74.83*78.98*2.07(mm) Dot Pitch： 0.0999*0.0999(mm) Color： 16.7M Contrast Ratio： 800 Response time： 35ms Brightness： 2000cd/m² Product type： TFT Display Type： Normal Black View Angle： ALL View Operating temperature： -20℃~+70℃ Storage temperature： -30℃~+80℃ Customization： Yes

4.3 inch 480*800 Resolution MIPI interface Normal Black tft LCD touch display screen module

4.3-inch TFT LCD display, HD resolution 480*800, supports MIPI interface, high brightness, and high contrast, suitable for a variety of handheld terminals and professional fields. Resolution: 480*800 Support Interface: MIPI Display Area: 56.16*93.6(mm) LCM Dimensions: 60.1*102.2*1.7(mm) Dot Pitch: 0.084*0.084(mm) Color: 16.7M Contrast Ratio: 800:1000 Response Time: 30ms Brightness: 550cd/m²（MIN） Product Type: TFT Display Type: Normal Black View Angle: U/D/L/R: 80/80/80/80 Operating Temperature: -20℃~+70℃ Storage Temperature: -30℃~+80℃ Customization: Yes
