The serial screen is a device that integrates the display screen and serial communication functions. It usually consists of a liquid crystal display, a drive circuit, and a serial communication interface. The device offers easy programmability and the ability to communicate with other devices via a serial connection. Users can create various graphical interfaces through predefined instructions or programming to realize the interaction between users and devices. These interfaces can include elements such as buttons, text boxes, diagrams, etc., enabling users to operate the device intuitively. It is widely used in various display fields such as industrial automation, smart home appliances, transportation rails, data centers, charging piles, electric medical, national defense security, and shared equipment.

For example, smart home appliances: household water purifiers, smart toilets, massage chairs, range hoods, air purifiers, water heaters, air detectors, etc.

Commercial equipment: digital power amplifier integrated machine, temperature controller, intelligent attendance machine, commercial oven, vending machine,

Energy storage equipment: mobile power supply, smart power exchange cabinet, new energy charging pile, etc.

Showing all 5 results

2.4 inch 240*320 RTP(4 Line) TTL UART Serial LCD display Module

PCBA Outside Dimensions： 42.72(W)*74.40(H)*11.80(T) LCM Outside Dimensions： 42.72(W)*60.26(H)*2.40(T) Active Area： 36.72(W)*48.96(H) Resolution： 240*320 Touch Type： RTP(4 Line) Interface Type： TTL UART (TXD/RXD) Input Voltage： 5.0V(VDD) Viewing direction： 12" O' Clock Backlight Luminance： 250 cd/m² Operating temperature： -20℃~+70℃ Storage temperature： -30℃~+80℃ Customisation： Hardware standard, software can be customized
Read more

3.5-inch 480×320 UART Serial Screen Display Module

Parameter of 3.5 inch 20*480 UART Serial screen display Module PCBA Outside Dimensions： 61.10mm*103.30mm*12.20mm LCM Outside Dimensions： 54.46mm*82.91mm*2.20mm Active Area： 48.96mm*73.44mm Resolution： 320*480 Touch Type： RTP Interface Type： TTL UART (TXD/RXD) Input Voltage： 5.0V Viewing direction： 12 O' Clock Backlight Luminance ：250cd/m2 Operating temperature： -20℃~+70℃ Storage temperature ：-30℃~+80℃ Customisation： Hardware standard, software can be customized
Read more

4.3 Inch UART Serial Screen Display Module

Parameter of 4.3 inch 480*272 UART Serial screen display Module PCBA Outside Dimensions： 121.90*73.20*17.20(mm) LCM Outside Dimensions： 105.50*67.20*3.00(mm) Active Area： 95.04*53.86(mm) Resolution： 480*272 Touch Type： RTP(4 line) Interface Type： TBD RS232 (TTL: No use R9) Input Voltage TBD： 12V (5.0V: LP2 to LP1) Viewing direction： All View Backlight Luminance： 350cd/m² Operating temperature ：-20℃~+70℃ Storage temperature： -30℃~+80℃ Customisation： Hardware standard, software can be customized
Read more

5.0 inch 800*480 RTP(4 Line) TBD RS232 Serial LCD display Module

PCBA Outside Dimensions： 143.50*80.90*16.00(mm) LCM Outside Dimensions： 120.70*76.00*3.00(mm) Active Area： 108.00(W)*64.80(H) Resolution： 800*480 Touch Type： RTP(4 Line) Interface Type： TBD RS232 (TTL: No use R9) Input Voltage： TBD 12V (5.0V: LP2 to LP1) Viewing direction： All view（IPS） Backlight Luminance： 350 cd/m² Operating temperature： -20℃~+70℃ Storage temperature： -30℃~+80℃ Customisation： Hardware standard, software can be customized
Read more

7.0 inch 1024*600 TBD TTL UART (RS232/RS485) Serial LCD display Module

PCBA Outside Dimensions： 190.5*105.4*18(mm) LCM Outside Dimensions： 165*100 *3.50(mm) Active Area： 154.21*85.92(mm) Resolution： 1024*600 Touch Type： G+G Interface Type： TBD TTL UART (RS232/RS485) Input Voltage： TBD 5.0V (12V: LP1 to LP2) Viewing direction： All view（IPS） Backlight Luminance： 400 cd/m² Operating temperature： -20℃~+70℃ Storage temperature： -30℃~+80℃ Customisation： Hardware standard, software can be customized
Read more
