2.06-インチAMOLEDディスプレイ製品の概要
The 2.06-inch AMOLED display is a high-performance, ultra-thin full-view display module that uses MIPI interface technology and supports 410×502 high-definition resolution. Its core advantage lies in the excellent color performance and ultra-fast response speed brought by AMOLED technology, combined with the normal black feature, it can provide deep black and high-contrast images. The module thickness is only 0.76mm, suitable for portable devices with strict space requirements, and supports a wide temperature working environment from -20℃ to +60℃ to meet industrial-grade application requirements.
Core characteristics and features of 2.06-inch AMOLED display
High-definition picture quality
· Resolution: 410×502, dot pitch 0.0807mm×0.0807mm, the picture is delicate and grainy.
· Color performance: supports 16.7M true color, contrast ratio up to 60000:1, and rich color levels.
Advanced technology
· AMOLED screen: self-luminous technology, low power consumption, fast response (3MS), no backlight leakage problem.
· MIPI interface: high-speed data transmission, 強力な互換性, and adaptability to a variety of main control chips.
· Full-view display: no color deviation at any angle, suitable for multi-person sharing scenarios.
Ultra-thin and durable design
· Display area: 33.09×40.51mm, module size 34.79×43.14×0.76mm, extremely thin and light.
· Brightness: 520cd/平方メートル, 強い光の下ではっきりと見えます.
· Environmental adaptability: working temperature -20℃~+60℃, storage temperature -30℃~+70℃, stable and reliable.
Flexible customization
· Support customer customization needs, including interface protocols, size fine-tuning, 等, and quickly respond to diverse project needs.
2.06-inch AMOLED display product highlights
· High contrast and fast response: 60000:1 contrast ratio with 3ms response time, dynamic images without smear, suitable for games, videos, and other scenes.
· Normal Black: Deep black performance, enhances visual immersion.
· Ultra-thin and low power consumption: AMOLED technology takes into account the thin and light design and energy-saving characteristics to extend the device’s life.
· Industrial-grade reliability: wide temperature range and compact structure, adapt to harsh environments.
2.06-inch AMOLED display application areas
Smart wearable devices
· Smartwatches, health bracelets, 等, high-definition screens with low power consumption characteristics to enhance user experience.
Industrial control panels
· Instruments, industrial control HMI interfaces, wide temperature adaptability, and high brightness ensure stable operation in outdoor/workshop environments.
医療機器
· Portable monitors, handheld diagnostic equipment, full-view display for multi-angle observation of data.
家電
· AR/VR glasses auxiliary screen, micro projector, ultra-thin design saves space.
Case introduction
· A high-end smartwatch brand: using this 2.06-inch AMOLED screen, using its high contrast and all-black display characteristics to achieve the ultimate visual effect of the dial UI, while the ultra-thin module frees up more space for integrated sensors inside the watch.
· Industrial handheld terminal: used in warehousing and logistics code scanning equipment, with -20℃ low-temperature startup capability and 520cd/m² high brightness, it can still clearly display barcode information in cold storage and strong light environments, 作業効率の向上.
結論
The 2.06-inch AMOLED display is based on high performance and high reliability and has flexible customized services. It is an ideal choice for smart wearables, 産業用制御, 医学, その他の分野, helping customers create differentiated terminal products.
