0.9 Inch Round TFT LCD Display Module Factory

解決: 128*128 インターフェースの種類: spi 表示領域: 23.04*23.04(mm) LCM寸法: 25.24*27.14*1.94(mm) 製品の寸法: 33*33*2.79(mm),Customizable appearance ドットピッチ: 180um*180um 色: 16.7m コントラスト比: 800 応答時間: 35MS 輝度: 800cd/平方メートル 製品タイプ: TFT 表示タイプ: ノーマルブラック 視野角: U/D/L/R: 85/85/85/85 (TYP) 動作温度: -20℃~+70℃ 保管温度:-30℃~+80℃ カスタマイズ: はい
0.95 Inch 120x240 AMOLED LCD Module

0.95 Inch 120×240 AMOLED LCD Module

サイズ: 0.95 inch Resolution: 120*240 インターフェースの種類: SPI Display Area: 10.80*21.60mm LCM Dimensions: 12.80*27.35*1.07mm Dot Pitch: 90um*90um Color: 16.7M Contrast Ratio: 10000(分) 応答時間: 3MS(MAX) 輝度: 480cd/m2 Product Type: AMOLED Display Type: Normally black View Angle: Full view Operating Temperature: -20℃~+70℃ Storage Temperature: -30℃~+80℃ customization: はい
1.28 inch knob screen

1.28 Inch 240×240 Metal Knurling Knob Screen

サイズ: 1.28 inch Resolution: 240*240 表示領域: 32.40*32.40mm LCM Dimensions: 52.5*27.02mm Dot Pitch: 0.135mm*0.135mm Color: 262K Contrast Ratio: 900 応答時間: 35MS Brightness: 250cd/m2 View AngleALL View TP TypeNO InterfaceTTL UART Upgrade MethodSerial Port Shell MaterialHardware knurling + plastic Feature Selection :ノブ + Press Operating temperature: -10℃~+60℃ Storage Temperature: -20℃~+70℃ UI PlatformLeveTop customizationSoftware, color and appearance can be customized
1.28 インチ 240*240 knob screen
1.28 インチ 240*240 knob screen

1.28 Inch 240×240 TTL UART Knob Screen

サイズ: 1.28 inch Resolution: 240*240 表示領域: 32.40*32.40(mm) LCM寸法: 48.90*35.20(mm) ドットピッチ: 0.135*0.135(mm) 色: 262K Contrast Ratio: 900 応答時間: 35MS Brightness: 250cd/m2 View AngleALL View TP TypeNO InterfaceTTL UART Upgrade Method: USB Shell MaterialPlastic Feature Selection: ノブ + Press Operating Temperature: -10℃~+60℃ Storage Temperature: -20℃~+70℃ UI PlatformLeveTop CustomizationSoftware, color, and appearance can be customized

1.28 inch 240×240 UART スマート円形ノブ 表示画面

のパラメータ 1.28 インチ 240*240 UART smart Circular knob Display screen PCBA Outside Dimensions: 41.00(W)*30.00(H)*22.50(T) mm LCM Outside Dimensions: 44.00(W)*44.00(H)*2.50(T) mm Active Area: 32.40(W)*32.40(H)mm Resolution: 240*240 色: 65K Touch TypeCOVER Interface TypeTBD TTL UART Input Voltage: 未定 5.0V (USB) 見る方向: All view Backlight Luminance :250 cd/m² Operating temperature: -20℃~+70℃ Storage temperature: -30℃~+80℃ Customisation: ハードウェア規格, ソフトウェアはカスタマイズできます

1.43 インチラウンドAMOLED LCDディスプレイモジュール

解決: 466*466 インターフェースの種類: MIPI、QSPI 表示領域: 36.35*36.35(mm) LCM寸法: 45*45*2.55(mm) ドットピッチ: 781つの*78um 色: 16.7m コントラスト比: 60000:1 応答時間: 3MS 輝度: 630 cd/平方メートル 製品タイプ: AMOLED 表示タイプ: ノーマルブラック 視野角: 完全なビュー 操作温度-20℃〜+70℃ 保管温度: -30℃~+80℃ カスタマイズ: はい

1.6 インチ400×400 UART スマート円形ノブ 表示画面

のパラメータ 1.6 インチ 400*400 UART smart Circular knob Display screen Resolution: 400*400 色: 65K Active Area: 39.84mm Backlight brightness: 350nits Contrast: 1000:1 視野角: IPS FLASH: 16M bytes Up to 128MB InterfaceRS485 Operating voltage DC Direct Current :4.5~5.5V DC 5V input: 120mA Serial port modeN81 Serial port levelTTL3.3V Interaction: ノブ + Press CommunicationUART UISupport customization Operating temperature :5V voltage at 60%RH -20~+70℃ Storage temperature: -30~+80℃ Operating humidity: -25℃,10%-90% その他の認証: RoHS

1.6 インチの円形ノブLCDスクリーンディスプレイ

解決: 400*400 表示領域: 40mm*40mm Dimension: 59 (外径)mm * 25.95 (厚さ) mm Material: アルミニウム合金シェル + ABS base Brightness: 350 cd/m2 USB Interface: はい, Micro-B connector Mode Selection: TTL ESD Contact discharge: ±4kv, 空気排出: ±8KV Operating Voltage: 4.5-5.5V Backlight: LED Colors: 65K Viewing Direction: IPS Operating Temperature: -20℃~+70℃ Storage Temperature :-30℃~+80℃ Customization: はい

1.6 Inch Round TFT LCD Display Panels Supplier

サイズ:1.6 Inch Resolution: 400*400 インターフェースの種類: MIPI 、QSPI Display Area: 39.84*39.84(mm) LCM寸法: 42.14*44.34*1.9(mm) 製品サイズ: 53*53*3.53 (mm) ドットピッチ: 33.2um*99.6um Color: 16.7M Contrast Ratio: 900 応答時間: 35ms Brightness: 300cd/m² Product type: TFT Display Type: Normal Black View Angle: Full view Operating temperature: -20℃~+70℃ Storage temperature: -30℃~+80℃ Customization: はい
1.6 LED付きのインチUARTラウンドノブスクリーン
1.6 LED付きのインチUARTラウンドノブスクリーン

1.6 LED付きのインチUARTラウンドノブスクリーン

パネルタイプ: TFT LCD Size: 1.6 inch Display Type: Normal Black Resolution: 400 x 400 ドットピッチ: 33.2um x 99.6um Colors: 16.7M Viewing Direction: IPS Interface Type: MIPI1 LANE TP Type: 12C Display Area: 39.84mm x 39.84mm Dimension: 53(H)x 53(V) x 3.53(T)(mm) 材料アルミニウム: 合金シェル + ABS base Brightness: 300 cd/m2 Touchpoints: 5 USBインターフェイス: はい, Micro-B connector Mode Selection: TTL ESD Contact discharge: ±4kv, 空気排出: ±8KV Operating Voltage: 4.5-5.5V Backlight: LED Operating Temperature: -20℃~+70℃ Storage Temperature: -30℃~+80℃ Customization: はい
